The rechargeable batteries are lead-lead dioxide systems. The dilute sulfuric acid electrolyte is absorbed by separators and plates and thus immobilized. Should the battery be accidentally overcharged producing hydrogen and oxygen, special oneway valves allow the gases to escape thus avoiding excessive pressure build-up.Otherwise, the battery is completely sealed and is, therefore, maintenance-free, leak proof and usable in any position.
Vision Deep Cycle AGM Batteries with a 10 year design life and up to 1200 cycles @ 50% DOD are well suited for use in Photovoltaic Energy Storage System (PV), Uninterrupted Power Supply (UPS) and other stand or emergency back-up power applications.
They offers the advantage of being maintenance free and is able to withstand high cycling upto 1200 cycles @ 50% DOD The battery can be used in many varied applications and may be applicable to many other, as indicated below:
Home Inverter and Home UPS Systems
Renewable Energy:
Photovoltaic Applications (Solar) and Eolic (Wind)
Emergency police radio communications
Back-up for commercial radio transmitters
Back-up for business computers
Back-up for manufacturing process that requires continuous power
Navigation safety aids
Emergency power for cable TV Systems
Emergency Ventilation Systems for farming
Vast range of UPS and stand-by power systems.
These Deep Cycle batteries can be used alone or in multiple battery banks, in parallel or series to obtain desired capacity and voltage of the system requirements.
Features:
Advanced pure lead technology.
Longer float & cycle life.
Stronger discharge performance.
Maintenance-free operation.
Special design to avoid thermal runaway.
Low self discharge.
Excellent consistency and reliability.
Can be mounted in any orientation.
Case and cover available in both standard and flame resistant ABS.
Dimensions and Weight
Length(mm) 522
Width(mm) 238
Height(mm) 218
Total Height(mm) 223
pprox. Weight(Kg) 62.5
Product Standards
You can expect Vision batteries to meet with the standards JIS, DIN, IEC60986-21/22 & BS6290-4. They have obtained ISO9001 & ISO14001 certification, UL approval (MH25860), CE approval for all types of batteries. All these render our batteries to be compatible with requirements of world-level equipment.
