Weight Approx. 43Kg
Package Material Black Powder Coat Steel
Dimensions 442mm x 431mm x 177mm
Communication Ports 1x RS 232, 3x RS 485, 1x CAN-BUS, 1x Dry Contact
Electrical Characteristics
Rated Capacity: 100Ah
Nominal Voltage: 51.2V
Nominal Energy: 5120Wh
Maximum Discharge Voltage: 43.2V (99% DoD)
Maximum Charge Voltage: 57.6V (0% DoD)
Maximum Charge Current 100A (1C) (1-4 units) 50A (5-10 units) 20A (11-15 units)
Recommended Discharge Current: < 80A (1-4 units) < 60A (5-10 units) < 40A (11-15 units)
Parallel Capability: 15 Units
Operating Temperatures :Charge / Discharge: 0°C to 60°C Storage: -20°C to 60°C
Cycle Life >6000 @ 80% (±16 years) >4500 @ 90% (±12 years)
Cell Design 16x 3.2V Prismatic Lithium Ion Phosphate (51.2V nominal)
Constant Discharge
51.2V Lithium 51-100 model
Constant current discharge at 25°C
Constant powerdischarge at 25°C
100A
1 hours
5120W
50A
2 hours
2560W
33A
3 hours
1706W
20A
5 hours
1024W
User Defined Settings Low DC Cut-Off @ 100% DoD 43.2V
Low DC Cut-Off @ 90% DoD 44.6V
Low DC Cut-Off @ 80% DoD 50.6VBulk Charge 57.6V
Float Charge 54.2V
99% 100% 1C 16 Cell HIGH CYCLE LIFE
EFFICIENCY DoD 100Ah MAX CHARGE
100Ah MAX DISCHARGE
TECHNOLOGY >6 000 CYCLE @ 80% DoD @ 25°
>4 500 CYCLE @ 90% DoD @ 25°
