PlayTech

We built our legacy in the PC Components space

Combo LuxPower 48V 6kW Hybrid Off-Grid Inverter 5.12kW HinnaESS Lithium + 2.4kW Solar Panels Installed

Store/Power Systems/Hybrid Off-Grid Power Systems/Hybrid Off-Grid Back-Up Systems

R29 975.00ZAR

INSTALLERS COMBO

Price incl. VAT (15%) R3 909.78ZAR

Inverter Included

1 x Luxpower 6kW Hybrid Off-Grid Inverter

Lithium Battery Included

1 x 51V 5.12kW HinaESS Hi-5 Lithium Battery

Battery Cable Included

1 x Battery Cable Pack

Solar Panels Included

4 x 600W Bifacial Mono Solar Panels

Delivery included

Warehouse Collection and Delivery

Quantity:

Save this product for later

Combo LuxPower 48V 6kW Hybrid Off-Grid Inverter 5.12kW HinnaESS Lithium + 2.4kW Solar Panels Installed

Store/Power Systems/Hybrid Off-Grid Power Systems/Hybrid Off-Grid Back-Up Systems

Product Details

Luxpower 6KW Off-grid Inverter - SNA 6000 With CT and WIFI

Product Features

Description:
General
- Model: SNA 6000 WPV
- Battery voltage: 48VDC.
- Dimension: 505mm x 330mm x 135mm
- Weight: 14.5kg
Inverter Output
- Waveform: Pure Sine-Wave.
- Rated Power: 6000VA/6000W.
- Parallel Capability: Yes, 16 units.
- AC Voltage Regulation (Battery Mode): 230VAC ± 5% @ 50/60Hz.
- Surge Power: 12000VA.
- Efficiency (Peak): 93%.
- Transfer Time: 15ms @ Single ; 30ms @ Parallele (For Home Appliances).
Solar Charger
- Maximum PV Array Power: 8000W.
- 2 MPPT Controllers
- PV Input Voltage Range: 100VDC ~ 480 VDC.
- MPPT Voltage Range: 120VDC ~ 385 VDC.
- Startup Voltage: 100VDC
- Maximum PV Input Current Per MPPT: 17A/17A
- Maximum PV Short Circuit Current Per MPPT: 25A/25A
- MPPT Maximum Efficiency: 99%.
- Maximum Solar Charge Current: 125A.
AC Charger
- Charge Current: 125A.
- AC Input Voltage: 230 VAC.
- Selectable Voltage Range: 110-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances).
- Frequency Range: 50Hz/60Hz (Auto sensing)
Build in BMS(Battery management System)
- BMS Compatible with
- Hina ESS
- Pylon
- Dyness
- BYD
- Shoto
- Revov
- UZ Energy
Wifi Remote Monitoring
Flexible Working Modes with settable charge and load power supply priority
Support Solar and AC take the load jointly

Hina ESS Hi-5 5.12kWh Lithium Battery (Rack Mount)

Description

General Data

• Model: Hi-5

• Cell Type: LFP

• Rated Power: 5.12KWH

• Rated Capacity: 100Ah

• Rated Voltage: 51.2V

• Charge Voltage: 56.5V

• Charge / Discharge Rating: 1C

• Maximum Charge / Discharge Current: 100A

• Discharge Peak Current: 105A – 15s / 120A – 0.5s

• Parallel Capacity: Up to 32 Units

• Mounting Type: Rack Mount

• Enclosure Protection: IP20

• Communication: CAN / RS485

• Humidity: 5% to 85% (Non Condensing)

• Working Temperature: -20°C to 55°C

• Storage Temperature: -10°C to 35°C

• Certification: CE UN38.3 / IEC62619

Weight	50 kg
Dimensions	48.1 × 45.26 × 16.5 cm

Recommended Base Load: 5Hour Discharge Rate

Recommended Base Load	Usage	No. of 100Ahr Lithium Batteries	Runtime hours
300W	4700Whr	1 x (90% DOD 4700Whr)	15.5
600W	4700Whr	1 x (90% DOD 4700Whr)	7.5
800W	4700Whr	1 x (90% DOD 4700Whr)	5.5
600W	9400Whr	2 x (90% DOD 9400Whr)	15.5
1000W	9400Whr	2 x (90% DOD 9400Whr)	9.5

The SUNFREE5 package includes:

1 x LuxPowerSNA6000 6kW Hybrid Off-Grid Inverter
1 x HinaESS Hi5 LiFePO4 Battery 5.12kW 51V (5kW)
1 x Battery Cable Pack
4 x 600W Bi-Facial Solar Panels (4.8kW Maximum Power)
