BPD series solar water-pump VFD adopts the dynamic VI MPPT technology and motor control technology, and is suitable for AC water pumps with prompt response, high efficiency and stable performance.
IP65 and fanless design, with convenient installation, maintenance free. Soft start function, over-voltage, over-current, over-load, lower-load protection, deceleration stop avoid water hammer effect etc.
Digital intelligent control can flexibly adjust and set the pump speed range.
Support driving single phase 220V motor and three phase 220V/380V motor . Support multiple types of pumps. Optional water level detection. Wide operation voltage range, multi PV strings configuration, save PV module cost
Specifications
Pump Inverter 1.5kW BPD-220V - BPD1K5TNAC
DC INPUT
Maximum DC Voltage: 450VDC
Starting Voltage: 100VDC
Minimum Working Voltage: 80VDC
Recommended MPPT Voltage: 100-400VDC
Number DC Inputs: 2 x MC4
Maximum Input Current: 12A
Bypass AC Input (Supporting Mains Input)
Input Voltage: 220/230/240 (1Phase) (-10% to +10%)
Input Frequency: 47-63Hz
AC Input Terminal: L,N,PE
AC OUTPUT
Rated Power: 1500W
Rated Current: 10.2A(1Phase) / 7.5A(3Phase)
Output Voltage: 0-Input Voltage
Output Wiring Mode: 1P2L 1Phase Motor 1Phase Control / 2P3L 1Phase Motor 2Phase Control / 3P3L Conected 3Phase Asynchronous Motor
