BPD series solar water-pump VFD adopts the dynamic VI MPPT technology and motor control technology, and is suitable for AC water pumps with prompt response, high efficiency and stable performance.
IP65 and fanless design, with convenient installation, maintenance free. Soft start function, over-voltage, over-current, over-load, lower-load protection, deceleration stop avoid water hammer effect etc.
Digital intelligent control can flexibly adjust and set the pump speed range.
Support driving single phase 220V motor and three phase 220V/380V motor . Support multiple types of pumps. Optional water level detection. Wide operation voltage range, multi PV strings configuration, save PV module cost
Specifications
Pump Inverter 5.5kW BPD-380V - BPD5K5TRACS
DC INPUT
Maximum DC Voltage: 800VDC
Starting Voltage: 220VDC
Minimum Working Voltage: 180VDC
Recommended MPPT Voltage: 220-750VDC
Number DC Inputs: 2 x MC4
Maximum Input Current: 20A
Bypass AC Input (Supporting Mains Input)
Input Voltage: 380V (3Phase) (-10% to +10%)
Input Frequency: 47-63Hz
AC Input Terminal: R,S,T,PE
AC OUTPUT
Rated Power: 5500W
Rated Current: 14A 3Phase
Output Voltage: 0-Input Voltage
Output Wiring Mode: 3P3L Connected 3Phase Asynchronous Motor
