System Deye Full Hybrid 48V 5kW Inverter 5.12kW Volta Stage1 Lithium
R35 650.00ZAR
Price incl. VAT (15%) R4 650.00ZAR
Inverter Included
Lithium Battery Included
Battery Disconnector Included
Battery Cable Included
1
Save this product for later
System Deye Full Hybrid 48V 5kW Inverter 5.12kW Volta Stage1 Lithium
Product Details
Deye 5.0kW Full Hybrid 5.12kW Volta Stage 1 Lithium Battery Storage
Description:
Higher yields.
- Improve self-consumption ratio up to 80%, reducing your electricity bill.
- DC/AC ratio up to 1.3, completely suitable for double-side PV modular.
- Two MPPT design, Max. efficiency of 97.6%.
User-friendly.
- LCD Touch screen and buttons, easy operation.
- Compatible with lithium-ion battery and lead acid battery.
- Web browser and mobile App monitoring supported.
Reliable.
- PV lighting protection, Anti-islanding protection, Leakage current protection etc.
- Support store energy from DG when needed, ensure the system working within 7*24H.
- IP65 protection degree, adapt to indoor and outdoor using.
- Automatically switch from on-grid to off-grid mode within 5ms.
- Zero exporting function, fast reaction within 200ms in zero export mode.
Smart.
- Programmable charging and discharging schedule.
- Both wind turbines and solar panels can be connected as DC input power.
- Max. 16 units can be paralleled for higher system power.
- Retrofitting of existing solar system to energy storage system.
Battery Input Data
- Battery Type: Lead-acid or Li-lon
- Battery Voltage Range (V): 40-60V
- Max. Charging Current (A): 120A
- Max. Discharging Current (A): 120A
- Charging curve: 3 Stages/Equalization
- External Temperature Sensor: Optional
- Charging Strategy for Lithium Battery: Self-adaption to BMS
PV String Input Data
- Max. DC Input Power (W): 6500W.
- PV input Voltage (V): 370V (100V-500V).
- MPPT Range (V): 125-425V.
- Start-up Voltage (V): 150V.
- PV Input Current (A): 11A + 11A.
- No. of MPPT Trackers: 2
- No. of Strings Per MPPT Tracker: 1+1.
AC Output Data
- Rated AC Output and UPS Power (W): 5000W
- Max AC Output Power (W): 5500W
- Peak Power(off-grid): 2 times of rated power, 10 S.
- AC Output Rated Current(A): 21.7.4A
- Max.AC Current(A): 25A
- Max Continuous AC Pass-through(A): 35A.
- Output Frequency and Voltage: 50Hz; 240Vac,
- Grid Type: THD<3%(Linear load<1.5%).
- Current Harmonic Distortion: THD<3% (Linear load<1.5%).
Efficiency
- Max. Efficiency: 97.60%
- Euro Efficiency: 96.50%
- MPPT Efficiency: 99.90%
Protection
- PV Arc Fault Detection: Integrated (Except European Type)
- PV Input Lightning Protection: Integrated
- Anti -islanding Protection: Integrated
- PV String Input Reverse Polarity Protection: Integrated
- Insulation Resistor Detection: Integrated
- Residual Current Monitoring Unit: Integrated
- Output over Current Protection: Integrated
- Output Shorted Protection: Integrated
- Output over Voltage Protection: Integrated
Certifications and Standards
- Grid Regulation: UL1741, IEEE1547, RULE21, VDE0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116, IE61727
- Safety Regulation: IEC62109-1, IEC62109-2
- EMC: EN61000-6-1, EN61000-6-3, FCC 15 class B
General Data
- Operating Temperature Range ( C ): -25—60 C , >45 C Derating
- Cooling: Fan
- Noise (dB): <30
- Communication with BMS: RS485; CAN
- Weight (kg): 20.5
- Size (mm): 580 X 330 X 208mm
- Protection Degree: IP65
- Installation Style: Wall-mounted
- Warranty: 5 years
It has 2 MPPTs which allows you to have 2 separate arrays. This means that if your roof is either east or west facing, you’ll be able to install your 2 arrays on each side of your roof , enabling you to produce solar power throughout the day.
You can expand your system by adding up to 16 inverters and you can monitor your daily usage remotely with an app.
.
- Lithium Battery FEATURES AND BENEFITS
The Volta Stage 1 Lithium battery is a high performance, 5.12kWh, scalable battery module perfect for expanding systems. A Single Stage 1 battery module allows up to 5120W of continuous discharge power.
- 1 C- rating allows single battery deployments for 5.12kW load
- 5.12kWhrs capable of 8 units in parallel totaling 40.96kWhrs
- RS485 and CAN communication ensures full compatibility with , Luxpower Voltronic, Deye, Victron, Sunsynk and more inverter manufacturers.
- 6000 Cycles 80% DOD allowing for more useable capacity from the battery
- 5 Year Standard warranty
- 10 Year Warranty (Under Warranty Terms)
Power Rating:
Recommended Base Load: 5Hour Discharge Rate
| Recommended Base Load | Usage |
No. of 100Ahr Lithium Batteries | Runtime hours |
| 300W | 5120Whr | 1 x (80% DOD 4100Whr) |
17 |
| 600W | 5120Whr | 1 x (80% DOD 4100Whr) | 8.5 |
| 1000W | 5120Whr | 1 x (80% DOD 4100Whr) | 5 |
| 800W | 10240Whr | 2 x (80% DOD 8200Whr) | 12.5 |
| 600W |
10240Whr |
2 x (80% DOD 8200Whr) | 17 |
Its max DC input voltage for 500V makes it ideal for 10 X 72 cell modules (320W - 540W) or 12 X 60 cell modules (260W - 400W).
The DeDy5.0 package includes:
- 1 x Deye 5kW Full Hybrid Solar Inverter 5.0kW 48V
- 1 x Volta Stage 1 48V 5.12kW Lithium Battery (5120W)
- 1 x Battery Cable Pack
- 1 x Battery Disconnect with 2 x 160A Blade fuses
Luxpower LUX5.0 System Performance:
The Deye 5000W Inverter have a rated power output of 5000W and have a maximum solar panel array power of 6500W
1 x Volta Stage1 5.12kW Lithium battery you will have 5120Whr usable energy if you discharge the battery to 100% depth of discharge (DOD) every day.
