System Sunsynk Lynks 48V 6kW Full Hybrid Inverter UP5000 Pylontech Lithium + 2.4kW Solar Panels Installed
R64 262.00ZAR
INSTALLERS COMBO
Price incl. VAT (15%) R8 382.00ZAR
Inverter Included
Lithium Battery Included
Battery Disconnector Included
Battery Cable Included
Solar Panels Included
Mounting System Included
DC Cables Included
AC Cables Included
AC DB Board Included
DC DB Board Included
Installation Included
Certification Included
Delivery included
1
Save this product for later
Have questions?
System Sunsynk Lynks 48V 6kW Full Hybrid Inverter UP5000 Pylontech Lithium + 2.4kW Solar Panels Installed
Product Details
Sunsynk Lynks 6kW Hybrid Inverter
Product Features
- Max PV input of 8000W dual MPPT with PV string current of 15A at 600V.
- Supports 1ph and 3ph flexible parallel connections with 6 units max for 36kW back-up.
- Generator connectivity with automatic On/Off control.
- 111A charge and discharge current.
- 10 second, 200% surge power backup overload capability.
- 24 hour real-time intelligent energy management - Bluetooth/Wi-Fi/App.
- Uninterrupted power supply with 4ms reaction time.
- Comes with a Wi-Fi/LAN datalogger, CT and more.
- 5-year warranty - extendable to 10-years - Free extension when paired with Freedom Won batteries.
- SA: NRS 097 certified and CoCT approved.
Battery Input Data
- Battery Type: Lead-acid or Li-lon
- Battery Voltage Range (V): 40-60V
- Max. Charging Current (A): 112A
- Max. Discharging Current (A): 112A
- Charging curve: 3 Stages/Equalization
- External Temperature Sensor: Optional
- Charging Strategy for Lithium Battery: Self-adaption to BMS
- Max. DC Input Power (W): 8000W.
- PV input Voltage (Voc): 600V
- MPPT Range (V): 90-520V.
- Start-up Voltage (V): 90V.
- PV Input Current (A): 16A + 16A.
- No. of MPPT Trackers: 2
- No. of Strings Per MPPT Tracker: 1+1.
- Rated AC Output and UPS Power (W): 5000W
- Max AC Output Power (W): 5000W
- Peak Power(off-grid): 2 times of rated power, 10 S.
- Max. Efficiency: 97.60%
- Euro Efficiency: 96.20%
- MPPT Efficiency: 99.90%
- PV Arc Fault Detection: Integrated (Except European Type)
- PV Input Lightning Protection: Integrated
- Anti -islanding Protection: Integrated
- PV String Input Reverse Polarity Protection: Integrated
- Insulation Resistor Detection: Integrated
- Residual Current Monitoring Unit: Integrated
- Output over Current Protection: Integrated
- Output Shorted Protection: Integrated
- Output over Voltage Protection: Integrated
- Grid Regulation: UL1741, IEEE1547, RULE21, VDE0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116, IE61727
- Safety Regulation: IEC62109-1, IEC62109-2
- EMC: EN61000-6-1, EN61000-6-3, FCC 15 class B
Pylontech UP5000 LiFePO4 Battery 1 x 5kW 52V
The Pylontech UP5000 4.8kW Lithoum Battery , 48V battery x 1
The Pylontech UP5000 is an economical and modular Life PO4 Solution for residential and light commercial applications
- 4.3kWh battery with a 90% DoD
- Stackable up to 16 Units (76kWh Total)
- Wide range Inverter compatibility
- 5-Year Limited warranty
- Module interface pedestal included (no cabinet required)
- 5U module design
- 6000 charge and discharge cycles
- Stacked horizontally onto each other to form stackable tower, brackets not included.
- Vertical mounting on floor or wall (shelf/bracket) with terminals facing upwards
- All Accessories Included:
- 2 x interconnected connectors
- 1 x inter modular comms cable
- Weight: 47 kg
-
- Battery Type: Lithium Ion
-
- Nominal Energy: 4800 Wh
-
- Depth of discharge: 95.00 %
-
- Voltage: 48 V
-
-
Continuous Discharge Rate (Normal Use): 4320 W
-
- Maximum Discharge Rate (5 Minutes): 4320 W
-
- Surge Discharge Rate (15 Seconds): 4800 W
-
- Maximum Charge Rate (5 Minutes): 4320 W
-
Recommended Base Load: 5Hour Discharge Rate
| Recommended Base Load | Usage
|
No. of 100Ahr Lithium Batteries | Runtime hours |
| 300W | 4320Whr | 1 x (95% DOD 4700Whr)
|
14.5 |
| 600W | 4320Whr | 1 x (95% DOD 4700Whr) | 7
|
| 800W | 4320Whr | 1 x (95% DOD 4700Whr) | 5.5 |
| 600W | 8640Whr | 2 x (95% DOD 9400Whr) | 14.5 |
| 1000W
|
8640Whr
|
2 x (95% DOD 9400Whr) | 8.5 |
The SUNPYL5 package includes:
- 1 x Sunsynk Lynksk 6kW Hybrid Inverter
- 1 x Pylontech UP5000 LiFePO4 Battery 4.8kW 48V (4.8kW)
- 1 x Pylontech Battery Cable Pack
- 1 x Battery Disconnect with 2 x 160A Blade fuses
- 4 x 600W Bi-Facial Solar Panels (4.8kW Maximum Power)
- Aluminium Roof Mount System
- AC and DC Distribution boards and Protection.
- AC and DC Cabling
- CoC and SSEG report
- Full Installation and Commissioning
- Wireless Monitoring and System Maintenance
